TM 55-1520-228-10
iv Change 11
Figure Title Page
7-5 Takeoff Chart A DELETED. . . . . . . . . . . . . .
7-6 Cruise Chart
A DELETED. . . . . . . . . . . . . . .
7-7 Drag Chart
A DELETED. . . . . . . . . . . . . . . . .
7-8 Climb – Descent Chart
A DELETED. . . . . .
7-9 Climb Performance
A DELETED. . . . . . . . .
7-10 Idle Fuel Flow Chart
A DELETED. . . . . . . . .
7-11 Maximum Torque Available (30
Minute Operation) Chart
C 7-48. . . . . . . . .
7-12 Torque Available (Continuous
Operation) Chart 7-52. . . . . . . . . . . . . . . . . . . .
7-13 Hover Chart 7-57. . . . . . . . . . . . . . . . . . . . . . . . .
7-14 Takeoff Chart DELETED
. . . . . . . . . . . . . . . . . .
7-15 Cruise Chart 7-63. . . . . . . . . . . . . . . . . . . . . . . . .
7-16 Drag Chart 7-77. . . . . . . . . . . . . . . . . . . . . . . . . .
7-17 Climb – Descent Chart
C 7-79. . . . . . . . . . . .
7-18 Climb Performance
C DELETED. . . . . . . . .
7-19 Idle Fuel Flow Chart
C 7-85. . . . . . . . . . . . . .
8-1 Exterior Check Diagram 8-4. . . . . . . . . . . . . . . .
8-2 Effects of Wind Azimuth on Aircraft 8-13. . . . .
9-1 Emergency Exits and Equipment 9-3. . . . . . . .
9-2 Autorotational Glide Characteristics
Chart 9-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9-3 Minimum Height for Safe Landing
after Engine Failure Chart 9-6. . . . . . . . . . . . .
