HEALLUX ALDEA ETC01-13 - Page 31

FR / EN
31
ø 10mm
C
392mm
B
G
H
≥600mm
≥750mm
x2G x2H
K
F
K
F
H
G
E
L
L
680mm366mm
D
a
b
a
c
D
I
I
1) Drill holes on the wall according to the instruction inside the box.
Warning: Be sure to keep the safety distances as shown on the above drawing.
