Heatcom HC 60 - Page 16

16
CONNECTIONS
All connections to the thermostat must be according to
national regulations and installed by authorized electri-
cians.
Power supply to the thermostat must be supplied
through 30mA RCD and overload protected through
max.16A fuses.
TERMINAL NO. DESCRIPTION
1 [L] Power supply
2 [N] Power supply
3 [N1] Load
4 [L1] Load
5 No function
6
10 kΩ oor sensor
7
