Heatiator GC150 - Page 5

Vent Sections
VK24
Vent Section
4-99 5 21322M
GC150 SERIES DIRECT VENT GAS APPLIANCE
RF6
Roof Flashing
VK5
EL45
A
Vent Section
Actual Useable
length length
VK12 12" 10
3
⁄4"
VK24 24" 22
3
⁄4"
VK36 36" 34
3
⁄4"
VK48 48" 46
3
⁄4"
CV7
Vertical Termination Cap
WS6
Wall Shield
FS6
Firestop Spacer
15942B, Starter Elbow
(Must be the elbow closest to unit
when horizontal venting begins.)
TA2
Horizontal Termination Kit
Termination Cap
