GLIDER ASSEMBLY
G1
M6 BOLT 47mm (x2)
G2
G8
M8 BOLT 39mm (x2)
THIN PLASTIC SPACER (x4)
7
72
2
8
G8
G8
G2
G6
M6 BOLT 35mm (x4)
3
4
15
13
5
3
4
8
5
14
Insert the metal frame (14) into the edge of the
fabric around the edge of the nest swing (15).
Connect the metal frames together and then fasten
them using then bolt at the end of the rope (13).
NEST SWING ASSEMBLY
&
27
8
8
9
9
G6
