SPECIFICATIONS
MM input: 3 mV /47 kOhm / 100 pF
MC input – adjustable –, sensitivity: 100 µV / 220 µV / 600 µV
impedance: 100 Ohm / 220 Ohm / 1 kOhm
Output voltage:
"Low Out": 220 mV / 100 Ohm
"High Out": 775 mV (0 dBm) / 22 Ohm
Gain: 50 dB (MM)
62-78 dB (MC, High Output)
Signal-to-noise ratio (A-weighted): 85 dB (MM)
78 dB (MC)
Channel separation: >90 dB
Distortion (THD, 1 kHz, 100mW): <0,08%
Bandwidth: 3 Hz-150 kHz (+/-1dB)
RIAA accuracy: 20 Hz-20 kHz (+/-0.5dB)
Power consumption: <10 W
Weight (amplification unit + Q-PSU): 3 kg
If within three years of the purchase date your Heed QUASAR proves to be defective for any reason
other than accident, misuse, neglect, unauthorised modification or fair wear and tear, Heed Audio Ltd.
will, at its discretion, replace the faulty parts without charge for labour.This factory warranty is valid only
for units sold into countries with no appointed Heed distributor. Service enquiries in countries with
appointed distributor should be addressed first to the supplying dealer and/or Heed distributor.
Warranties granted in these countries are entirely at the discretion of distributor.
FACTORY CONTACT
DISTRIBUTOR CONTACT
WARRANTY
HEED Audio Kft. (Ltd)
Tel/Fax: +36 1 2947401
Reviczky Gyula u. 9-11 eMail: info@heedaudio.hu
H-1181 Budapest
Hungary Web: www.heedaudio.com
Heed QUASAR - Users Manual 1.1 (2010)
