21.1.5 Error messages
The following error messages may be displayed, if there are problems related to drives:
Possible error messages
8040 Heat sink temp. in UV 1xx
8041 Excessive Iz in UV 1xx
8042 Leakage current in UV 1xx
8043 No inverter-ready signal
8060 Leakage current in UV 1xx too high
8080 Uz UV 1xx too high
8130 Motor brake defective
8140 Error field orientation
8300 Motor brake defective
8310 No current in brake test
8410 I2t value is too high
8430 Load is too high
8450 I2t value of motor is too high
8460 I2t value of power module is too high
8410 I2t value is too high
8620 Load is too high
8410 I2t value of motor is too high
8650 I2t value of power stage is too high
8800 Signal LT-RDY inactive
8A00 No inverter enabling
8A10 AC fail
8A20 Powerfail
8A40 Enabling of axis group
8A50 Inverter is not ready
8B10 Wrong traverse direction
8B20 Error field orientation
8B30 Motor temp. too high
8B40 No drive enabling
8B50 Axis module not ready
8B60 Error in axis module
8B60 Overcurrent cutoff
8B70 External drive lock
8B80 External drive stop
8BB0 Motor temp. too low
8BC0 Motor current too high
8BD0 Excessive servo lag
B900 Error in supply voltage
C330 Motor temp. too high
C350 Axis module not ready
C380 Motor not controllable
C3B0 Motor does not rotate
C3C0 Motor current too high
C4A0 Inverter is not active
C4C0 No motor current
E150 Inverter ready
E160 Inverter is not ready
Axis motor current not equal 0
Movement monitoring
CC inverter for axes RDY = 0
CC inverter for axes RDY = 1
CC inverter
for spindle RDY
= 0
CC inverter for spindle RDY = 1
Speed out of range
Nominal speed value too high
Synchronization monitoring
I2t warning
I2t monitoring
Switch-off of power module (IGBT)
Power module ready
Temperature of power module
MC nominal-to-actual position error too large
Motor temperature
Excessive offset
Positioning error
Dif. in position <> shaft speed too high
Excessive servo lag
Spindle speed out of tolerance range
Spindle motor current not equal to 0
Standstill monitoring
Inverter is not ready for operation
Power supply unit is ready
DC-link voltage >>
DC-link current >>
Other error messages may also indicate problems with a drive.
