July 2010 27 – 473
X45:
iTNC control panel
D-sub connector, 37-pin
MC 42x (B/C) Connecting cable ID 263 954-xx TE
Female Pin layout Male Female X2: Male
1RL0 1Gray/Red11
2RL1 2Brown/Black22
3RL2 3White/Black33
4RL3 4Green/Black44
5RL4 5Brown/Red55
6RL5 6White/Red66
7RL6 7White/Green77
8 RL7 8 Red/Blue 8 8
9RL8 9Yellow/Red99
10 RL9 10 GY/PK 10 10
11 RL10 11 Black 11 11
12 RL11 12 Pink/Brown 12 12
13 RL12 13 Yellow/Blue 13 13
14 RL13 14 Green/Blue 14 14
15 RL14 15 Yellow 15 15
16 RL15 16 Red 16 16
17 RL16 17 Gray 17 17
18 RL17 18 Blue 18 18
19 RL18 19 Pink 19 19
20 SL0 20 WH/GY 20 20
21 SL1 21 Yellow/Gray 21 21
22 SL2 22 Green/Red 22 22
23SL3 23White/Pink2323
24 SL4 24 Gray/Green 24 24
25 SL5 25 Yellow/
Brown
25 25
26 SL6 26 Gray/Brown 26 26
27 SL7 26 Yellow/Black 27 27
28 RL19 28 White/Yellow 28 28
29 RL20 29 Gray/Blue 29 29
30 Do not assign 30 Pink/Blue 30 30
31 RL21 31 Pink/Red 31 31
32 RL22 32 Brown/Blue 32 32
33 RL23 33 Pink/Green 33 33
34 Spindle override (wiper) 34 Brown 34 34
35 Feed-rate override (wiper) 35 Yellow/Pink 35 35
36 +5 V override potentiometer 36 Violet 36 36
37 0 V override potentiometer 37 White 37 37
Housing External shield Housing External
shield
Housing Housing
