VI. HOW TO ASSEMBLE THE FAN
Align Catch of the
Front Guard with the
illustrated position of
the Rear Guard.
Press guards sequentially with
both hands.
Self-Catch Installation.
Lock nut of blade
• Lock nut of
blade anticlockwise,
and then install the
front fan cover
Guard catch
Front grill
Lock nut of blade
• Lock nut of blade
anticlockwise, and then install
the front fan cover
Blade
• Pull the blade to rotate after
installing, so as to ensure that the blade
can be normally rotated
Lock nut of grill
• Screw the lock nut of grill clockwise,
and in the meantime, fix the rear grill
