HELLER HPH2000 - Product Features and Diagram; Heater Assembly Steps

FEATURES
Fig.1:
Fig 2:
1) Heating part
2) Knob
3) Body
4) Display
5) Pull switch
6) Column-locking ring
7) Upper telescoping column
8) Screws
9) Intermediate column
10) Screws
11) Lower column
12) Power cord
13) Base cover
14) screw
15)Base Assembly
16) Base fixing
17）ring with cord stop
ASSEMBLY INSTRUCTIONS
To assemble, follow these instructions:
1. Attach the counterweight inside the base using the 4 screws provided.
2. Attach the lower column (11) to the base using the 6 screws provided and then insert the ring nut
(13) and ring (17).
3. Connect the intermediate column (9) to the lower one and then the upper one (7), attaching them
with the screws provided.
4. Connect the heating part to the upper column and attach it by tightening the knob on the screw.
5. Hook the electric cord to the ring.
6. Fix the base on the ground to keep stable. And there are three base fixings (16) to fix the base by
screws to the ground.
7. Maximal Height: 2.1 m
8. You can choose the short version, while you join direct the Upper Post Assembly (7) and the
Lower Post Assembly (11).
