HER CHEE SS-50 - Page 14

ADLY MOTO 1-12
no sparking or
weak
sparking strong
INFORMATION FOR PREPARATION
SPARK PLUG NO SPARKING
Diagnose
Check and Adjust
loosen no loosen
normal abnormal
normal
abnormal
normal abnormal
change spark plug and
check again
check spark plug, cap,
ignition coil loosen?
check C.D.I unit socket
loosen ?
check the terminal of
C.D.I unit unimpeded?
measure resistance
check relate spare parts
Reason of Trouble
the previous spark plug damage
spark plug cap loosen
main switch damage
pulser coil damage
coil damage
lighten coil damage
the previous C.D.I unit damage
socket damage
normal
abnormal
main switch damage
socket, joint connect abnormal
change CDI unit
abnormal
change ignition coil
the previous coil damage
