ADLY MOTO 1-4
INFORMATION FOR PREPARATION
LOCKING TORQUE
Adopt the standard torque locking for the item unlisted.
STANDARD TORQUE：
Type Locking Torque (kg-m)
5 mm Screw 0.4
6 mm Screw 1.0
6 mm Hex Washer Face Bolt / Nut 1.2
8 mm Hex Washer Face Bolt / Nut 2.7
10 mm Hex Washer Face Bolt / Nut 4.0
CHASSIS：
Locking Place Quantity Dia. (mm) Locking Torque (kg-m)
Spanner Nut of Handle Steering Steam 1 25 7.0
Front Wheel Axle Nut 1 10 4.5
Rear Axle Nut 1 14 11
Rear Brake Arm Screw 1 5 0.6
Upper Screw of Rear Shock Absorber 1 10 4.0
Lower Screw of Rear Shock Absorber 1 8 2.7
Engine Mounting Bracket 1 8 6.0
ENGINE：
Locking Place Quantity Dia. (mm) Locking Torque (kg-m)
Screw of Cylinder Cap 4 6 1.0
Flywheel Nut 1 10 3.8
Clutch Jacket Nut 1 11 3.8
Driving Disc Nut 1 28 5.5
Nut of Transmission Disc 1 10 3.8
Oil-check Screw 1 8 1.3
Joint Screw of Exhaust Manifold 2 6 1.2
Exhaust Pipe Support Screw of Muffler 2 6 1.2
Spark Plug 1 14 1.4
Bolt of Crank Shaft Case 6 6 10
Bolt of Engine Installation 1 8 5.0
