Heras Delta 3a - Installation Symbols Guide

5
Delta 3 a/b [duo] /prefab
8
Use an open-end wrench
The number specifi es the
insertion size in mm.
8
Use an Allen key
The number specifi es the
insertion size in mm.
15
Use a screwdriver
The symbol specifi es the type of
screw. The number specifi es the
size of the screw.
15
Use a electric screwdriver
The symbol specifi es the type of
screw. The number specifi es the
size of the screw.
8
Use a drill
The number specifi es the drill bit
diameter in mm.
Ensure that the specifi ed parts
are level.
Dig a hole
Do not perform the work on
your own.
Use a lifting tool/hoisting
system.
Use concrete
Follow the instructions on the
packaging.
Use epoxy
Follow the instructions on the
packaging.
Cu
Use a brass hammer.
Use sandpaper.
Line of travel of the gate
Specifi es the line of travel of the
gate.
Fence line
Specifi es the position of an
(existing) fence line.
Viewing angle
A different viewing angle is
used.
Extra to order
Not included in gate kit.
14
Page reference
Specifi es a reference to a page.
24
Drawing reference
Specifi es a reference to a
drawing number.
Explanation of symbols
14
