Deluxe Hot Wire Cutting Table
Part: #8500 – DHWT
01 Housing/ Cutting Table
02 Overarm
03 Circle cutting attachment
04 Extension Rail
05 Knurled screw long
06 Washer
07 Cutting wire (PN6555)
(Φ0.18mm, length 5m)
08 Knurled screw-short
09 Slider
10 Knurled screw for overarm
11 Contact screw
12 Rubber foot
13 Miter Angle gauge
14 Clamp spring
15 Knurled screw for wire
16 Level/ Temperature
adjustment knob
17 Switch
18 Socket for foot pedal
19 Clamping
20 Washer for clamping
21 Screw for clamping
22 Foot pedal
23 Circuit board
24 Lower housing cover
25 Screw for lower
housing cover
26 Screw for transformer
27 Transformer
28 Strain relief
29 Screw for strain relief
30 Power cord
