13
At “RES”, fuel will flow from the reserve
fuel supply to the carburetor. Use the
reserve fuel only when the main supply is
exhausted. Refill the tank as soon as
possible after switching to “RES”. The
reserve fuel supply is 1 litre usable.
motorcycle
3
(1) Fuel tank cap (2) Ignition key
(3) Lid
4. For locking, press the lid gently and turn
the key clockwise.
2. Remove the cap by turning it anti-
clockwise.
3. Do not overfill the tank. There should be
no fuel in the filler neck (4).
1. To remove the fuel tank cap (1), insert
the ignition key (2), turn it anti-
clockwise and open the lid (3) as shown
in the picture.
1
2
3
tank.
Fuel tank capacity is 11 litres (minimum)
including reserve supply of 1 litre.
Do not park the motorcycle under direct
sunlight as it causes evaporation of petrol
due to heat and deterioration of paint gloss
due to ultra violet rays.
