22
To open, insert the key (1), rotate it
clockwise, pull the cover (2), and slide it
sideways to disengage it from the hook (3).
1
To close, engage the hook and press gently.
Hold the key in clockwise direction, slide
the cover back and release the key.
The tool kit (1) is stored in the utility box.
S o m e e m e rg e nc y r e p a i rs , m i n or
adjustments and parts replacement can be
performed with the tools contained in the kit.
+, - No. 2 Driver- 1 No.
Tool bag- 1 No.
Grip- 1 No.
Box wrench 16 x 14- 1 No.
1
2
The first aid kit (2) is stored in the utility
box. Some emergency first aid can be
performed by medicine contained in the kit.
2 3
3) Water Proof Plaster - 1 No.
5) Gauze (Rolled Bandage) - 1 No.
Kit contains the following items :
6) Sterilised Elastic Plaster - 1 No.
7) First Aid Bag - 1 No.
4) Elastic Bandage - 1 No.
2) Sterilised Dressing - 1 No.
1) Anticeptic Cream - 1 No.
