1
31
A
B
Check that the clutch cable routing is
correct.
If proper adjustment cannot be obtained or
the clutch does not work correctly, visit
your Authorized Hero MotoCorp
workshop.
2
3
4
To adjust the free play, loosen the lock
nut (3). Turn the adjusting nut (4) to
obtain the specified free play. Tighten
the lock nut and check the adjustment.
