38
6
7
(2) Upper level mark
(3) Lower level mark
(4) Negative terminal
(5) Positive terminal
(1) Battery
(6) Bolt
(7) Bracket
Check the battery electrolyte. The
electrolyte level must be maintained
between the upper (2) and lower (3) level
marks on the battery. If the electrolyte
level is low, disconnect the cable from
battery negative (4) and positive (5)
terminals, remove the bolt (6) and remove
the bracket (7) for access to the battery.
Remove the battery filler caps.
4
5
3
2
