Bi-Wiring
MLCX 2
Set TW Level controls on 0 dB
and adjust emission level
through the proper amplifier
Caution
Mono-Wiring
MLCX 3
Electric
connection
in phase
Connectors
Connectors must be connected according to the right polarity. Positive pole is indicate by “+”
and by a red point on the speaker terminals.
CAUTION The connection phase of all the components determines acoustic results. Make sure
all connection phases are right, as from instructions.
MILLE line crossovers were designed to allow single amplification and multi-amplification. You
can make the filter functioning suitable to different types of installation simply by moving some
switches. Thanks to MILLE systems multi-amplification, you will get very high SPL systems, with
bursting dynamics.
Caution
Disconnect the system before changing the jumpers position in the printed circuit board.
