Heston Blumenthal everdure FORCE - Procedure Force Grill: Removing the Burner Tubes; STEP 01: Remove Phillips Head Screws; STEP 02: Slide Burners and Remove Ignition Cables; STEP 03: Inspect and Clean Burners

19
Assembly, Operation & Maintenance Instructions
PROCEDURE FORCE GRILL: REMOVING THE BURNER TUBES
Note: Please note the grill plates need to be removed before removing the burner tubes.
STEP 01
/Remove the Phillip head screws x 2
STEP 02
/Slide the burners toward the rear of the grill & remove ignition cables from the burner sub
assembly and lift the burner rail assembly out of the gas grill.
STEP 03
/Inspect the burners for insect webs and nests or any other blockages, the burner tube &
ports can be cleaned with a thin piece of wire if required.
To replace the burner assembly repeat the above in the reverse order, ensure the burner
are seated correctly over the gas control outlets when replacing.
