Display assembly subcomponents
Item Component Spare part number
(1) Display bezel 686254-001
(2) Webcam/microphone module (includes double-sided adhesive) 686285-001
(3) 15.6-in, LED, SVA, HD, BrightView display panel 687700-001
(4) Display Hinge Cover Kit (includes left and right display hinge covers) 686260-001
(5) Display hinges (includes vertical support brackets) 686262-001
(6) Display panel cable (includes webcam/microphone module cable) 686256-001
22 Chapter 3 Illustrated parts catalog
