Assembly Guide

ENSURE ALL ITEMS LISTED ARE PRESENT PRIOR TO STARTING ASSEMBLY PROCEDURE

SCALE OF ITEMS WILL VARY TO AID VISUAL IDENTIFICATION

Part Ref: 0213-01

Qty: x2

Part Ref: 0213-04

Qty: x2

Part Ref: 0205-09

Qty: x3

Part Ref: 0205-12 (1850 x 625mm)

Qty: x9

Part Ref: 0205-13 (1850 x 425mm)

Qty: x3

Part Ref: 0213-03 (1850 x 324mm)

Qty: x2

Part Ref: 0205-02

Qty: x2

Part Ref: 0205-74

Qty: x1
