HID Mercury MR16in-S3 User Manual

S8 S7 S6 S5 S4 S3 S2 S1 Selection
ON ON ON ON OFF Address 30
ON ON ON ON ON Address 31
OFF OFF 115,200 BPS
1
OFF ON 9,600 BPS
ON OFF 19,200 BPS
ON ON 38,400 BPS
OFF Encrypted communication not required
2
ON Encrypted communication required
2
1. Firmware revisions prior to 1.30.1, this setting is 2,400 BPS.
2. Firmware revisions prior to 1.30.1, S8 is not defined. Set to the OFF position.
2.5.1 Jumpers
Jumper Description
J3 RS-485 termination, install in first and last units only.
Note: All other jumpers are for factory use only.
PLT-05250, A.1 10 August 2022
Powering
Trusted Identities
HID®Mercury™ MR16in-S3 Processor
Installation and Specifications

HID Mercury MR16in-S3 Specifications
