HID Mercury MR16in-S3 User Manual

Revision E assembly:
The processor is for use in low voltage, class 2 circuit only.
Primary power 12 to 24 V DC ± 10%, 350 mA maximum
Outputs Two Form-C relays
Normally open contact (NO) contact: 5 A @ 30 V DC resistive
Normally closed contact (NC) contact: 3 A @ 30 V DC resistive
Inputs 16 unsupervised/supervised, standard EOL: 1k/1kΩ, 1%, ¼ watt
2 unsupervised, dedicated for cabinet tamper and UPS fault monitoring
Communication
RS-485, 2-wire. 9600, 19200, 38400, or 115200 bps
CABLE REQUIREMENTS
Power 18 AWG, 1 twisted pair
RS-485 24 AWG, 120Ω impedance, twisted pair with drain wire and shield, 4,000 feet
(1,200 m) maximum
Alarm inputs 1 twisted pair, 30Ω maximum
Outputs
As required for the load
MECHANICAL
Dimension 6 inches (152 mm) W x 8 inches (203 mm) L x 1 inches (25.4 mm) H
Weight
9 oz. (250 g) nominal
ENVIRONMENTAL
Storage temperature -55°C to +85°C
Operating temperature 0°C to +70°C
Humidity
5% to 95% RHNC
UL294, 6
th
edition Performance Levels
Feature Level
Standby Power I
Endurance IV
Line Security I
Destructive Attack I
These specifications are subject to change without notice.
PLT-05250, A.1 14 August 2022
Powering
Trusted Identities
HID®Mercury™ MR16in-S3 Processor
Installation and Specifications
