8 EN
Using the appliance
B
1
Depending on its technical specifications, your machine may be fitted with either a single
water inlet hose connection (cold water) or a double connection (hot and cold water). The
hose with a white cap should be connected to the cold-water inlet and the hose with a red
cap to the hot-water inlet (if applicable).
• To prevent water leaking from the joints, 1 or 2 nuts (depending on the technical
specifications of your machine) are delivered in the hose packaging. Fit these nuts to the end
of the water inlet pipe(s) to be connected to the water supply.
2
Connect the new water inlet hoses to a 1.9 cm threaded tap.
• Connect the white end of the water inlet hose to the white water inlet valve located at the
rear of the machine and the red end of the hose to the red water inlet valve (if available).
• Tighten the connections by hand. If in doubt, consult a qualified plumber.
• A water pressure between 0.1 and 1 MPa is required for optimum operating efficiency (a
pressure of 0.1 MPa corresponds to a flow rate of more than 8 L of water per minute with a
fully open tap).
3
Once all the connections have been made, carefully turn on the water supply and check
for any leaks.
4
Make sure that the new water inlet hose is not pinched, twisted, bent, kinked or crushed.
• If the machine is fitted with a hot water inlet connection, the temperature of the water
supplied must not exceed 70°C.
PLEASE NOTE : The appliance must be connected to
the water supply network using the new connection sets
supplied with the appliance; used connection sets should
not be reused.
