The Highyes Electric Spin Scrubber, Model A10, is a versatile cleaning device designed for various household tasks. It is marketed as a "7 in 1" product, indicating its multi-functional capabilities through a range of interchangeable brush heads.

Function Description:

The Electric Spin Scrubber utilizes high-performance lithium batteries and a strong 390-magneto motor, offering two distinct speeds for effective cleaning. It comes equipped with seven different brush heads, allowing users to conveniently switch them based on specific cleaning needs. The device supports USB charging via an international standard Type-C charging line, enabling a quick 3-hour charge. Its circuit design incorporates several protective features, including charge and discharge protection, blocking protection, and low power reminders. Charging instructions are provided, and a five-section LED power display indicates the battery level. The product is designed to comply with safety certification and environmental standards globally, aiming to provide a reliable and eco-friendly user experience.

Important Technical Specifications:

Product Name: Electric Spin Scrubber
Product Model: A10
Gear Speed: 420R/min (high speed) / 330R/min (low speed)
Decibel Value: ≤70DB
Input Voltage: 5V/1A
Battery Capacity: 2500mAh
Battery Life: 80 minutes at high speed, 100 minutes at low speed
Charging Time: Approximately 180 minutes (3 hours)
Waterproof Level: IPX7 (Note: The main body cannot be immersed in water, but the charging port should be sealed during cleaning.)

Usage Features:

The scrubber's design emphasizes ease of use and versatility.

Connect Head: Features a buckle structure design that allows for easy interchange of different brush heads.
Power Button: A long press for 2 seconds turns the machine on or off (it defaults to high speed upon startup). A short press switches between high and low speeds.
Type-C Charging Port: Supports 5V/1A charging and is protected by a soft rubber waterproof cover.
Power Display: A five-bar LED indicator shows the battery level:
- 5 bars: 100% power
- 4 bars: 80% power
- 3 bars: 60% power
- 2 bars: 40% power
- 1 bar: 20% battery (indicates low battery, requiring timely charging).
Charging Guide: When the battery is low, the last battery bar flashes. During charging, all five bars flash in a "horse race" pattern. Once fully charged, the indicator light stays on for 5 minutes and then turns off. It's important to note that the product does not support use while being charged.
Brush Head Assembly: To replace a brush head, first turn off the machine. Gently swing the brush head and pull it out vertically. The new brush head's groove should align with the convex groove of the connecting bracket and snap in vertically. For the cloth brush, four pieces need to be installed on the magic sticky base.
Handle Assembly: The telescopic rod can be attached to the machine head by rotating and tightening the threaded end. The two pole sections of the rod are also rotated and tightened together. To adjust the length, rotate the indicator arrow to "ON" to unlock, extend the rod to the desired length, and then rotate the arrow to "OFF" to lock and secure it.
Wall-mounted Usage: A hook is provided to stick on a flat wall. The pole of the scrubber can then be squeezed into position from the front for storage.

Purpose of Accessories (Brush Heads):

Big brush: Suitable for cleaning oil and dirt in bathrooms, kitchens, living rooms, toilets, windows, and glass surfaces.
Small brush: Ideal for cleaning small flat areas such as hand wash basins, kitchen sinks, and furniture.
Sharp brush: Designed for cleaning corners, seams, car wheels, and hard-to-reach areas in home kitchens, bathrooms, or around fume machines.
Brush head holder: Used to attach the cloth, sponge, and fiber brushes.
Imitation wool brush: Primarily used for polishing, waxing, or decontamination of high-grade household electrical appliances and automobile surfaces.
Sponge brush: Mainly used for washing car paint surfaces, glass, etc., without causing surface scratches.
Fiber brush: Primarily used in the kitchen for cleaning stoves, range hoods, and other areas that are particularly difficult to clean.
Cloth brush: Mainly suitable for living room floors, glass, tea tables, car surface cleaning, polishing, and other general purposes.

Maintenance Features:

Cleaning: Before cleaning, ensure the charging port is covered. Avoid using metal materials like steel wire, abrasive cleaners, or corrosive liquids (e.g., gasoline or acetone) on brush heads and the fuselage. Brush heads can be washed under a tap or using a machine.
Important Note: The main body of the spin scrubber cannot be immersed in water.
Post-Cleaning: After cleaning, shake off any moisture from the product and wipe it with a dry cloth.

Safety Warnings:

Check accessories carefully before use.
Do not place the charger in wet conditions.
Ensure the charging hole is sealed when cleaning.
Dry the surface promptly after cleaning to keep the product dry.
This product is not intended for use by individuals (including children) with reduced physical, mental, or emotional capabilities, or lack of experience and knowledge, unless supervised or instructed by a responsible person. Children should be supervised to prevent them from playing with the product.
Do not use hot water for cleaning to avoid the risk of scalding.
Only use the standard charger provided for this product.
Do not touch the rotating parts with your hands while the device is working.
