HIKVISION DS-2CE12DFT-PIRXOF28 User Manual

 OSD menu with configurable parameters
 24-hour color image
 Smart light
 PIR detection
 Built-in speaker
1.2 Overview
1.2.1 Overview of Type I Camera
Power Cord
Video Cable
Alarm Cable
Switch Button
Lens
PIR
Siren
Main Body
Bracket
Figure 1-1 Overview of Type I Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.2 Overview of Type II Camera
Enclosure
Main Body
Mounting
Base
Switch Button
Alarm Cable
Video Cable
Power Cord
Lens
PIR
Figure 1-2 Overview of Type II Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.

HIKVISION DS-2CE12DFT-PIRXOF28 Specifications

General

Brand	HIKVISION
Model	DS-2CE12DFT-PIRXOF28
Category	Security Camera
Language	English
