Explosion-Proof Optical & Thermal Network Bullet Camera·Quick Start Guide
21
Figure 3-1 Dimension of the Wall Mounting Bracket
Steps:
1. Disassemble the PT joint.
PT Joint
PT Joint Top
Screws
PT Joint Bottom
Figure 3-2 PT Joint
2. Install the PT joint top to the mounting base of the camera with
four UNC1/4 screws.
