HIKVISION DS-2TD2528T-7/Q User Manual

Explosion-Proof Optical & Thermal Network Bullet Camera·Quick Start Guide
29
Figure 3-14 Cover the Junction Box
8. Seal the junction box.
1). Insert the T-shaped plug into the sealing ring.
2). Fix the cable gland to seal the junction box.
T-shaped Plug
Cable Gland
Sealing Ring
Figure 3-15 Seal the Junction Box
Result:
The Installation is complete, see the figure below.

HIKVISION DS-2TD2528T-7/Q Specifications

General

Brand	HIKVISION
Model	DS-2TD2528T-7/Q
Category	Security Camera
Language	English
