General| Product color | Black |
|---|---|
| Channels quantity | 16 channels |
| Maximum frame rate | 30 fps |
| Total storage capacity | 12000 GB |
| Video compression formats | H.264 |
| Playback resolutions supported | 1920x1080, 1280x1024, 1280x720, 1024x768, 704x576, 704x480 |
| Audio input | 4 |
| RS-485 ports | 1 |
| BNC input ports | 16 |
| BNC output ports | 2 |
| USB 2.0 ports quantity | 3 |
| Ethernet interface type | Gigabit Ethernet |
| HDD interface | Serial ATA |
| Maximum HDD capacity | 4000 GB |
| Power requirements | 100-240 VAC, 5A, 50-60Hz |
| Power consumption (typical) | 35 W |
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
Weight and Dimensions| Dimensions (WxDxH) | 445 x 390 x 70 mm |
|---|
