A6 version
III. Operation Instruction
Keypad needs a password, for example,
Enter 0~9 in any combination of numbers on the keypad, press confirm button, press button A or button B
according to the actual situation. Press button A to select receiver channel 1, press the button B
to select receiver channel 2.
It is only sending out signal when you press the correct password, if you enter the incorrect password then no
response. It is only recorded the last entered 6 bit password, for example, if the correct password is "123456",
then "*123456" is the right password ( ‘’ *’’ representative any number); but "123456#" is wrong password.
If press wrong password, there is no response for either button A or button B, you should to press the correct
password again.
It should be less than 4 seconds when pressing each password number, otherwise you need to press again.
Factory set up password for channel 1 and 2 are 000000
IV. Password Modification
Channel 1 password modification: Keep press button A. Eg:
Step Press button LED
1、Keep pressing button A longer than 2 seconds
Button A（keep pressing）
“A”light up
2、Write the old password and press button A
000000 button A “A+1” light up
3、Write the new password and press button A
654321 button A “A+1+2” light up
4、
Write the new password again and press button A
654321 button A “A+1+2”Flash together twice and then off
Channel 2 password modification: Keep press button B. Eg:
Step Press button LED
1、
Keep pressing button B longer than 2 seconds
Write the old password and press button B
000000 button B “B+1” light up
3、
Write the new password and press button B
123456 button B “B+1+2” light up
4、
Write the new password again and press button B
123456 button B “B+1+2”Flash together twice and then off
Attention 1：If the two passwords are same, you can press button A or button B after pressing the password.
Attention 2：It is not valid if you don’t enter the number when set up the password.
Attention 3：It is not valid if you press two different passwords when set up new passwords or the wrong old
password.
V. Regular Operation
Channel 1---regular operation in the practical application, Eg:
Press the password of channel 1 654321
Press button A Button A
Less than 4s, then re-press button A Can transmit signal
More than 4s, then re-press button A Can’t transmit signal
