Hiniker 6000 - Prince 3.5 Inch Diameter X 16 Inch Stroke Cylinder 3;4 O-Ring Ports

Page 3
SERIES 6000 ROW CULTIVATOR
11/10
PRINCE 3.5 INCH DIAMETER X 16 INCH STROKE
CYLINDER 3/4 O-RING PORTS
S
E
C
3
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
81002605
855-001-404
850-001-794
855-001-413
856-001-252
81002604
855-001-387
856-001-254
850-001-796
*
*
Piston Rod
#8 SAE Plug
Tube
Butt
Gland
Piston
Lock Nut 7/8-14 Uni-Torque
Hex Nut
Tie Rod
O-Ring
O-Ring
1
1
1
1
1
1
1
4
4
2
1
12
13
14
15
16
17
18
19
*
*
*
*
*
850-001-804
840-001-206
856-001-239
856-001-258
81002580
Backup Washer
O-Ring
U-Cup
Backup Washer
Wiper
Clevis Pin
Hair Pin Clip
Clevis Assembly
Seal Kit Includes Items 10, 11, 12, 13, 14, 15 & 16
Complete 3 1/2 x 16 Cylinder Assembly
*NOTE: Items marked “*” are available in seal kit.
2
1
1
2
1
1
2
1
DWG. NO. 2301
Cylinder Identification Hiniker P/N 81002580
Prince Pin SAE-9316A-5P
