Hiniker 6000 - Coulter Adjusting Strap

Page 4
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
4
2
1
5
6
6
4
4
3
COULTER ADJUSTING STRAP
DWG. NO. 2878
1
2
2
3
4
5
GAUGE WHEEL 4 X 16 TIRE ASSEMBLY
DWG. NO. 2879
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
81004123
81003196
81004002
Tire 4 x 16
Half Wheel
Bearing With Outer Bushing
1
2
1
4
5
950-001-232
951-005-064
Hex Head Cap Screw 5/16-18 x 5/8 Gr. 5
2-Way Lock Nut 5/16-18
7
7
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
51004047
81004046
81004050
Coulter Pull Strap
Strap
Adjusting Washer
1
1
6
4
5
6
953-003-019
81004078
953-003-017
Spring Pin 1/2 x 2
Spring
Spring Pin 5/16 x 2
2
1
2
