SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
4
STORAGE OF
PARKING STAND
5
4
6
3
2
4
5
7
5
4
1
PARKING STAND ASSEMBLY
DWG. NO. 1384A
WARNING
7
6000
HINIKER
3
2
1
ROW UNIT
3
1
2
1
4
5
WARNING
HINIKER
6000
3
2
6
SERIAL NO. ENDING 100
OR HIGHER
BOLT ON UPPER HITCH
SERIAL NO. ENDING 100
8/30, 8/36, 12/30
SERIAL NO. ENDING 101
OR HIGHER
8/30, 8/36-38-40, 12/30
SERIAL NO. ENDING 100
12/36-38-40, 16/30
TILLAGE UNIT MOUNTING HARDWARE
DWG. NO. 3015
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
805-001-332
875-001-038
81004034
81005577
81004186
81005600
U-Bolt 5/8 (Fits 7 x 7)
U-Bolt 3/4 (Fits 7 x 7)
Support Plate (For 5/8 U-Bolts)
Support Plate (For 3/4 U-Bolts)
Spacer Strap (Fits 5/8 U-Bolt)
Spacer Strap (Fits 3/4 U-Bolt)
A/R
A/R
A/R
A/R
A/R
A/R
4
5
6
7
810-002-371
950-001-087
81003020
875-001-035
950-001-230
Spacer Plate (8/36 Only)
Hex Head Cap Screw 5/8 x 1 1/2 (8/36 Only)
U-Bolt 5/8 (Fits 5 x 7)
U-Bolt 3/4 (Fits 5 x 7)
Hex Head Cap Screw 5/8 x 9 1/2
4
8
A/R
A/R
4
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
81006028
805-001-847
875-001-038
875-001-035
Stand Weldment
Mounting Bracket Weldment
U-Bolt 3/4 x 7 13/16 Inch Center (Fits 7 x 7)
U-Bolt 3/4 x 7 13/16 Inch Center (Fits 5 x 7)
1
1
2
2
4
5
6
7
952-001-006
951-001-009
953-002-021
953-005-001
Lock Washer 3/4
Hex Nut 3/4-10
Clevis Pin 5/8 x 3 1/2 Long
Hair Pin Cotter .120 x 2 3/8 Long
4
4
1
1
