Hiniker 6000 - Rigid Toolbar

Page 2
SERIES 6000 ROW CULTIVATOR
11/10
RIGID TOOLBAR
4 ROW 36138, 6 ROW 30, 6 ROW 36/38/40
8 ROW 30, 8 ROW 36/38140
DWG. NO. 3011
S
E
C
1
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
875-001-038
810-002-234
810-002-235
810-002-236
810-002-237
810-002-238
81004338
952-001-006
951-001-009
810-002-080
810-002-079
810-002-085
810-001-920
810-001-284
U-Bolt 3/4
Toolbar (170”) (4/36-38)
Toolbar (198”) (6/30)
Toolbar (246”) (6/36-38)
Toolbar (258”) (8/30) 6/40)
Toolbar (322”) (8/36-38)
Toolbar (338”) 3/8 Wall (8/36-38-40) (10-30)
Lock Washer 3/4 Inch
Hex Nut 3/4-10
RH Lower Hitch Assy (Includes Items 1, 3 & 4)
(See Sect. 4 Pg. 7)
LH Lower Hitch Assy (Includes Items 1, 3 & 4)
(See Sect. 4 Pg. 7)
Upper Hitch Assy (Includes Items 1, 3 & 4)
(See Sect. 4 Pg. 7)
Parking Stand Assy (Includes Items 1, 3 & 4)
(See Sect. 4 Pg. 6)
End Plate
10
1
1
1
1
1
20
20
2
2
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
810-001-475
950-002-006
951-002-002
950-001-003
952-001-001
951-001-003
850-001-354
815-001-004
850-001-305
810-001-473
850-001-285
850-002-426
81004129
81004136
81004186
81004181
Block Removing Rod
Whiz Lock Bolt 5/16 x 3/4
Whiz Lock Nut 5/16-18
Hex Bolt 1/4-20 x 1
Lock Washer 1/4 Inch
Hex Nut 1/4-20
SMV Sign
SMV Mount Strap
Tape Reflector (Red)
Notice Decal
Tape Reflector (Yellow)
Caution Decal
6000 Decal
Hiniker Decal
Spacer Strap
Decal Bag (Includes Items 18, 19, 20, 21, 22
& 23)
1
8
8
2
2
2
1
1
2
1
2
1
2
2
2
