Hiniker 6000 - Rolling Shield and Rotary Hoe Wheel

Page 17
SERIES 6000 ROW CULTIVATOR
11/10
S
E
C
5
18
36
34
39
40
34
34
34
31
30
31
34
34
34
39
40
29
34
26
23
19
17
26
27
11
27
32
32
27
28
31
14
41
41
31
28
27
32
32
27
10
26
23
19
33
19
23
25
25
23
19
9
22
37
5
21
38
8
13
4
16
15
2
1
12
3
24
20
23
19
19
20
24
35
6
36
37
38
7
22
23
ROTARY HOE OPTION
LIVE AXLE
ROLLING SHIELD OPTION
ROLLING SHIELD AND ROTARY HOE WHEEL
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
805-001-332
810-002-364
810-002-363
810-001-487
810-001-497
810-001-500
850-002-403
810-002-357
810-001-179
810-001-499
810-001-498
810-001-490
810-002-361
810-001-590
950-001-060
950-001-131
950-001-259
950-001-274
951-001-007
951-001-008
U-Bolt 5/8 x 7 5/8 Inch Center
Right Mount Bracket
Left Mount Bracket
Bracket Weldment
Spring Bracket
Rod
Compression Spring
Outer Channel Weldment
Inner Channel Assembly (Includes Items 33 & 41)
Left Rolling Shield Weldment
Right Rolling Shield Weldment
Spacer
Tube
Axle (Rolling Shield Only)
Hex Head Cap Screw 1/2-13 x 5 Gr. 5
Hex Head Cap Screw 5/8-11 x 4 1/2 Gr. 5
Hex Head Cap Screw 1/2-13 x 7 Gr. 5
(Rolling Shield Option Only)
Hex Head Cap Screw 1/2-13 x 10 Gr. 5
(Rolling Shield Option Only)
Hex Nut 1/2-13
Hex Nut 5/8-11
2
1
1
1
1
1
1
1
1
1
1
2
1
1
2
1
1
1
5
5
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
950-001-125
950-008-008
952-001-004
952-001-005
952-002-005
952-004-059
952-002-010
952-003-005
810-002-462
810-002-461
515-301-012
810-001-591
955-001-002
810-002-463
953.005.002
953.001-010
828-001-005
810-001-493
810-002-467
810-002-466
515-301-004
Hex Head Cap Screw 1/2-13 x 1 1/2 Gr. 5
Square Head Set Screw 1/2-13 x 3/4
Look Washer 1/2 Inch
Lock Washer 5/8 Inch
Flat Washer 1/2 Inch
Flat Washer 9/16 x 1 3/4 x .250
Flat Washer 1 Inch (Rolling Shield Option Only)
Flat Washer 1 Inch SAE (Rolling Shield
Option Only)
Axle Tube (Rotary Hoe Option Only)
Sleeve Axle Bearing (Rotary Hoe Option Only)
Dust Cap
Spacer (Rolling Shield Option Only)
Grease Fitting 1/4-28 UNF
Axle Spacer (Rotary Hoe Option Only)
Hair Pin Cotter .178 x 3 9/16
Cotter Pin 1/4 x 1 1/2
Lock Collar
Spring Cap Weldment
Wheel Assembly With Washer Weldment
Washer Weldment (Service Replacement Part)
Bronze Bearing
2
2
5
5
2
2
5
2
1
1
2
4
1
8
1
1
2
2
2
4
2
DWG. NO. 1855
