(Note) Outdoor unit of Models 170~454 consists of 2~3 base units in the combination pattern as given in the table
above, and any combination pattern other than specified in the table is unacceptable.
Model 170 Model 190~212 Model 232~308
Model 324~340 Model 364~398
Model 420~454
1.2 Various Indoor Units and Combinations
The line-up of new Hi-Flexi R series indoor units has been extended up to 104 indoor units in 12 types to meet various
building requirements.
: Available
Indoor Unit Type
Nominal Capacity (kBtu/h)
07 09 12 14 17 18 22 24 27 30 38 48 54 76 96
Ceiling Ducted Type (Low Static Pressure)
Low-Height Ceiling Ducted Type
4-Way Cassette Type
Wall-Mounted Type
Floor-Concealed Type
Ceiling and Floor Type
Slim Ceiling Ducted Type
Compact 4-Way Cassette Type
Ceiling Ducted Type (High Static Pressure)
1-Way Cassette Type
2-Way Cassette Type
Low-Height Ceiling Ducted Type (DC)
