Max. Number of
Connectable I.U.
Recommended
Number of
Connectable I.U.
Min. Capacity at
Individual Operation
( kBtu/h )
Able to Connect a Set of Outdoor Unit with up to 64Indoor Units
Utilizing an inverter control, a wide range of operation capacity control is also available. A maximum total
combination horsepower of 140% and a minimum total combination horsepower of 50% can be chosen by
combination of the indoor units when compared with the nominal outdoor unit capacity. Therefore, the new
system can meet individual air conditioning requirements in most office buildings
Model
Range of
Combination
Capacity
( kBtu/h )
07
50~140%
59 32
64 38
64 38
64 38
64 38
64 38
64 38
AVWT-76*
AVWT-96*
AVWT-114*
AVWT-136*
AVWT-154*
AVWT-170*
AVWT-190*
AVWT-212*
AVWT-232*
AVWT-250*
AVWT-268*
AVWT-287*
AVWT-306*
AVWT-324*
AVWT-340*
AVWT-364*
AVWT-382*
AVWT-398*
AVWT-420*
AVWT-438*
AVWT-454*
IMPORTANT:
1.
In a system where all indoor units operate at the same time, total of these indoor units should not be larger than combined
capacity of the outdoor units, or otherwise overload may occur under severe working condition or within narrow operating range.
2.
3.
4.
Compared to indoor unit of 12kBtu/h, those of 07kBtu/h and 09kBtu/h, if set to high-velocity airflow, may deliver airflow in too low
temperature, so prior to installation, check the operation environment and installation location with much care. Where the
equipment is installed at a location which may be subject to the circumstance as stated above, number of indoor units connected
may be smaller than the number recommended in the table above.
In a system where not all indoor units operate at the same time, total capacity of these indoor units can be up to 140% of
total capacity of the outdoor units.
If the system is applied in cold area (with ambient temperature below -10°C) or high heat load environment, the total capacity
of indoor units should be less than combined capacity of outdoor units and total length of pipeline shall be less than 300m.
