9. Screw out lower hinge, change it to
the near hole site, and then screw up
and mount washer.
10. Just remount to the step 8,change
part①to left and part②to right and then
fix them with screws④ . Finally install
part③.
11. Move the lower door and adjust its
position to align lower hole site and
upper hinge axis. Turn the middle
hinge by 180, change the washer on
the axis to the upper side, adjust the
middle hinge to the appropriate
position and then install it.
12. Screw out The upper hinge axis,
turn the upper hinge over and fix axis
on it. Then place it at side for use.
Hisense Refrigerator
7
Note: washer may
stick to lower door.
washer
② Front foot fixed board
④ Self-tapping screws
③ Adjustable bottom feet part
① Lower hinge part（right）
Lower hinge part (left)
Note: washer may
stick to lower door.
Washer
13. Just remount to the step 2,change
upper hinge cover③to left and fix them
with screws② and then install the
screw cover①. Finally, change screw
hole cover④to right .
③Upper hinge cover (left)
②screw
①Screw cover
④Screw hole cover
①
②
③
④
14. Open the upper door, mount door
racks and then close it.
