Hisun HS5DUTV-2 - Page 186

CHASSIS
- 186-
7
Bolt M10×1.25×20
8
8
Shed bar assy Ⅳ
1
No.
Part Name
Qty
Remarks
9
Shed bar assy Ⅲ
1
10
Shed bar assy Ⅱ
1
11
Shed bar assy Ⅰ
1
12
Hexagon socket head screw M10×1.25×45
4
13
Cap nut M10×1.25
4
14
Spring washer -10
4
15
Roof shed joint rubber boot C
4
