THE STRUCTURE OF STEERING WHEEL
PART
DIASSEMBLING THE PARTS OF THE
STEERING WHEEL
Remove:
• screw M5×20 ①
• Decoration cover for steering wheel ②
• Horn assembly ③
a. Takes down the screw ①
b. Takes down the decoration cover for steering
wheel ② and horn assembly ③
c. Use the special tools pull out the steering
wheel ④.
CHECKING THE PARTS OF THE STEERING
WHEEL
Check:
• steering wheel ①
• rocky ledge ②
• reverse turning clearance ③
crack/ break Replace.
loose/play Adjust.
the steering wheel to rotate whether nimble,
do not have stagnation. Adjust the torque
of the steering wheel whether obviously
increase Adjust.
NOTE:
The steering force cutting which exerts to
transfers in steering wheel outflow boundary
is smaller than 245N.
