Inspect fastens nut of the steering wheel
whether does have flaw and fissure , if it is,
must replace.
Check the internal spline between the steering
wheel and steering column whether have
damaged, if the attrition is serious, must
replace the steering wheel.
NOTE:
The tolerance clearance between the internal
spline on the steering wheel and outer spline
on the steering column is smaller than
0.1mm.
WARNING
：
If
find some problems in the check, it should
be service immediately to ensure the normal
work of the steering system.
DIASSEMBLING THE STEERING COLUMN
PARTS
Remove:
• Front cover
• connection covers part
• steering wheel cover
• display board
• steering wheel
a. Takes down the parts of the front panel and
the connection covers part and the display
board and the steering wheel center covers
b. Take down the steering wheel
• bolt
