Hisun HS5DUTV-2 - Page 205

CHASSIS
- 205-
21
Right rear brake sheet
2
No.
Part Name
Qty
Remarks
22
Middle brake assy
1
23
Hexagon flange bolt M6×30
1
24
Rear right disc brake clamp
combination
1
25
Rear left disc brake clamp combination
1
26
Hydraulic line three
2
27
Brake pad assy
1
28
Rear brake disc
1
29
Parking disc brake plate
1
30
Hexagon Bolt M8×1×20
4
31
Front Right Brake Pad
2
32
Front disc brake plate
2
