Hisun HS5DUTV-2 - Page 223

CHASSIS
- 223-
REPLACING THE PARKING BRAKE PADS
1. Check:
• brake pad
• brake pad plate
Damage/wear Replace
2. Measure:
• brake pad thickness
Out of specification Replace the brake
pads as a set.
Brake pad wear limit
1.0 mm (0.04 in)
3. Install:
• brake pads
• pad spring
NOTE:
Always install new brake pads, new brake
pad
shims, new insulators, and a new brake pad
spring as a set.
4. Check:
• brake fluid level
