CHASSIS
- 229-
CHECKING THE MASTER CYLINDER
1. Check:
• brake master cylinder
Wear/scratches Replace the brake master
cylinder assembly.
• brake master cylinder body
Cracks/damage Replace.
• brake fluid delivery passage
(brake master cylinder body)
Blockage Blow out with compressed air.
2. Check:
• brake master cylinder kit
Scratches/wear/damage Replace as a set.
3. Check:
• brake fluid reservoir
• brake fluid reservoir diaphragm
Cracks/damage Replace.
ASSEMBLING THE BRAKE MASTER
CYLINDER
WARNING ：
• All internal brake components should be
cleaned and lubricated with new brake fluid
only before installation.
Must use DOT4 Brake Fluid
• Whenever a master cylinder is disassembled
replace the piston seals and dust seals.
