CHASSIS
- 231-
INSTALLING THE BRAKE MASTER
CYLINDER
1. Install:
• brake master cylinder
16Nm (1.6 m · kg,11 ft ·
lb)
2. Install:
• brake pipe
19Nm (1.9 m · kg,13 ft ·
lb)
• washer plate
• brake hose
• union bolt
27Nm (2.7 m · kg,19 ft ·
lb)
3. Fill:
• brake fluid reservoir
Must use DOT4 Brake Fluid
NOTE:
Brake fluid may damage painted surfaces or
plastic parts. Always clean up spilled brake
fluid immediately.
4. Air bleed:
