DISASSEMBLING THE UNIVERSAL JOINT
Remove:
• universal joint
a. Remove the circlips ①.
b. Place the universal joint in a press.
c. With a suitable diameter pipe ② ben- eath
the yoke ③, press the bearing ④ into the pipe
as shown.
d. Repeat the steps for the opposite bearing.
e. remove the yoke.
NOTE:
It may be necessary to lightly tap the yoke
with a punch.
