Hisun HS5DUTV-2 - Page 303

ELECTRICAL COMPONENTS
- 303 -
SEAT
No.
Part Name
Qty
Remarks
Removing the seat
1
Seat cushion Ⅰ
1
2
Rubber socket, seat latch
2
3
Backrest assy
1
4
Pan head screw with cross recess
M6×25
8
5
Lock catch for the safety belt Ⅰ
2
6
Hexagon flange nut M10×1.25
2
7
Hexagon flange step bolt
M10×1.25×20-φ14×5
4
8
Hexagon flange bolt M10×1.25×20
2
9
Hexagon flange nut M10×1.25
4
10
Hexagon bolt with flange
M10×1.25×20
2
11
Safety belt
2
