Check the condition of each of the signal
system’s circuits. Refer to “CHECKING
THE SIGNAL SYSTEM”.
CHECKING THE SIGNAL SYSTEM 检查信
号系统
1. If the brake lights fail to come on:
(1). Bulb and bulb socket
• Check the bulb and bulb socket for
continuity.
CONTINUITY
(2). Bake light switch
Refer to “CHECKING THE SWITCH”.
• Connect the pocket tester (DC 20 V) to
the
bulb socket connector.
Tester (+) lead Dark/Brown terminal
①
Tester (–) lead Black terminal ②
• Turn the main switch to “ON”.
• Turn the light switch to “ ” or “ ”.
• Check the voltage (12 V) of the “Yellow”
lead on the bulb socket connector.
Properly connect the signal system.
Replace the bulb and/or bulb socket.
Replace the brake light switch.
To Next Page
