Hisun HS5DUTV-2 - Page 92

MAINTENANCE AND ADJUSTMENT OF THE EV
92
Dimensions:
Overall length
Overall width
Overall height
Seat height
Wheelbase
Minimum ground clearance
Minimum turning radius
2,800mm (110.23 in)
1,615mm（63.58 in）
1,850mm（72.83 in）
860mm（33.85 in）
1,850mm（72.83 in）
260mm（10.24 in）
3,420mm (134.64 in)
Basic weight:
824kg (1816.6 lbs)
Max. speed:
25 MPH (40.2 km/h)
Motor:
Model
Motor type
Power
Rated torque
Voltage
Capacity
频率
Cooling mechanism
YDQ5-4-11151
AC induction motor
5Kw
3630rpm
33V
125A
125.6Hz
Air
Controller：
Model
450 - Amp Sevcon GEN4 controller with
multi-mode driving and regenerative
braking
